RF Receiver
NOTE:
Take care not to scratch the crash pad and related parts.
- Disconnect the negative (-) battery terminal.
- Remove the crash pad center panel.
Refer to CRACH PAD CENTER PANEL .
- Remove the RF receiver after loosening the mounting nut (1EA) and disconnecting the connector.
