Repair procedures: Inspection: Disposal

  1. Fully extend the piston rod.
  2. Drill a hole on the (A) section to remove gas from the cylinder.
    Fig 1: Identifying Drill Area Of Cylinder
    G08805337Courtesy of HYUNDAI MOTOR AMERICA
    CAUTION:
    • The gas coming out is harmless, but be careful of chips that may fly when drilling.
    • Be sure to wear safety goggles or eye protection.
