Repair procedures: Inspection

  1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
  2. Remove the crash pad lower panel. (Refer to the "CRASH PAD ")
  3. Remove the crash pad side switch assembly (A).
    Fig 1: Identifying Crash Pad Side Switch Assembly
    G08807657Courtesy of HYUNDAI MOTOR AMERICA
  4. Check the continuity between the switch terminals as the ESC OFF switch is engaged.
    Fig 2: Crash Pad Side Switch Terminals Continuity Reference Chart
    G08807658Courtesy of HYUNDAI MOTOR AMERICA
