Main display in XM mode
| XM1 | XM band |
|---|---|
| CH 100 | Channel Number |
| Dance | Category name |
| Dance hits | Channel name |
| Britney Jean Spears | Artist name |
| TOXIC | Song title |
| P1/P2/P3/P4/P5/P6 | Preset channel number |
| 100 | Current preset channel number |
| *The disc icons reflect the actual disc status in the CD changer (for CDC Models). | |
| * User can select the base display of channel info. (Option 1 or Option 2) | |
| * Information display mode is extended mode. (Display allowable characters.) | |
