Control Units
CONTROL UNITS LOCATION
| Component | Location |
|---|---|
| A/C Control Module | Behind center of dash. See Figure. |
| A/C Inverter Unit | Right rear wheelwell, behind trim panel. See Figure. |
| BCM | Below left side of dash. See Figure. |
| Driver Seat Warmer Control Module | In driver seat back. See Figure. |
| DVD Module | Below center console. See Figure. |
| ESP Control Module | Left rear of engine compartment, below brake master cylinder. See Figure. |
| Immobilizer Control Module | Base of steering column. See Figure. |
| Passenger Seat Warmer Control Module | Under passenger's seat. See Figure. |
| PCM | Left rear of engine compartment. See Figure. |
| PODS Module | Under seat. See Figure. |
| Safety Power Window Module | Driver's door. See Figure. |
| SRS Control Module | Below front of center console. See Figure. |
| 4WD ECM | Behind right side of dash. See Figure. |
