ESCL (Electronic Steering Column Lock): Removal

  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to "CRASH PAD ")
    Fig 1: Identifying Crash Pad Lower Panel
    G06103655Courtesy of HYUNDAI MOTOR CO.
  3. Disconnect the electronic steering column lock connector (A).
    Fig 2: Identifying Electronic Steering Column Lock Connector
    G06103663Courtesy of HYUNDAI MOTOR CO.
  4. Remove the electronic steering column lock (A). (Refer to STEERING COLUMN & SHAFT )
    Fig 3: Identifying Electronic Steering Column Lock
    G06103664Courtesy of HYUNDAI MOTOR CO.
