Special Service Tools
SERVICE TOOLS REFERENCE
| Tool(Number and Name) | illustration | Use |
|---|---|---|
| Deployment tool 0957A-34100A | Airbag deployment tool | |
| Deployment adapter 0957A-38510 | Use with deployment tool. (DAB) | |
| Deployment adapter 0957A-2E110 | Use with deployment tool. (PAB) | |
| Deployment adapter 0957A-3F100 | Use with deployment tool. (SAB, CAB) | |
| Deployment adapter 0957A-38500 | Use with deployment tool. (BPT) | |
| Dummy 0957A-38200 | Simulator to check the resistance of each wiring harness | |
| Dummy adapter 0957A-3F000 | Use with dummy (SAB, CAB) | |
| Dummy adapter 0957A-2E100 | Use with dummy (PAB) | |
| Dummy adapter 0957A-2G000 | Use with dummy (DAB, BPT) | |
| DAB : Driver Airbag PAB : Passenger Airbag SAB : Side Airbag CAB : Curtain Airbag BPT : Seat Belt Retractor Pretensioner |
||
