ECM Update (Service Campaign TF4) (SC TF4)

Publication date: 2012-01-01
Reference number: SC TF4
Supersedes refnos: 11-01-014, 11-01-014-1, 12-01-003

ECM UPDATE (SERVICE CAMPAIGN TF4)

SERVICE CAMPAIGN BULLETIN

Reference Number(s): 12-01-003, Date of Issue: January, 2012

HYUNDAI:	2007-2009 TUCSON (JM)
GROUP:	CAMPAIGN

Superceded Bulletin(s): 11-01-014-1, Date of Issue: January, 2012

REVISION HISTORY

This bulletin supersedes TSB# 11-01-014-1 to add Customer Notification Letter, see page 5 of 5.

IMPORTANT: Dealers must perform this Service Campaign on all affected vehicles whenever an affected vehicle is in the shop for any maintenance/repair, or is brought in to the dealer in response to the attached customer communication sent from Hyundai.
When a vehicle arrives at the Service Department, access Hyundai Motor America's "Warranty Vehicle Information" screen via WEBDCS to identify open Campaigns.

DESCRIPTION

This bulletin provides information related to the ECM software update of some 2007~2009 MY TUCSON (JM) 2.0L vehicles to improve fuel adaption logic.

Applicable Vehicles:

2007-2009MY TUCSON(JM) with 2.0L engine (June 7, 2006 to June 26, 2009 production)

GDS INFORMATION

EVENT #

DESCRIPTION

221 (or later compatible event)⁽¹⁾

"JM 2.0 FUEL ADAPTION LOGIC IMPROVEMENT."

⁽¹⁾	the latest event that appears in the Engine Auto Mode event list for the particular vehicle/engine)

WARRANTY INFORMATION

Model	Op Code	Operation	Op Time
JM	10C005R0	ECM UPGRADE	0.3

NOTE: Submit claim on Campaign Claim Entry Screen.

CAUTION: In the event of AUTO MODE Update failure (after it initiated the progress bar):

You must then attempt MANUAL MODE. Use the ECM P/N from the vehicle's ECM label if the correct ECM P/N is not clear from the ROM ID Table.
Replacing an ECM without carefully documenting that a MANUAL MODE update attempt was made, will result in claims charge back.

ROM ID INFORMATION TABLE

Verify the ECM ROM ID before updating the vehicle's software. Refer to the table below.

ROM ID INFORMATION

MODEL YEAR	PCM P/N (A/T Trans)	ECM P/N (M/T Trans)	ROM ID
MODEL YEAR	PCM P/N (A/T Trans)	ECM P/N (M/T Trans)	PREVIOUS	NEW
2007	39180-23132	39181-23132	M7NCSQ1A M7NCSQ2A M7NCSQ2B	M7NCSQ2C
2008	39180-23133	39181-23133	M8NCSU1A M8NCSS1B M8NCSS1A M8NCSU1B	M8NCSU1C
2009	39180-23134	39181-23134	M9NCSC1A M9NCSD1A M9NCSD1B M9NCSD1C	M9NCSD1D

GENERAL PRECAUTIONS

Connect the USB cable between the GDS and the VCI.
Connect the 16-pin DLC connector from the VCI into the DLC located under the driver's side dash.

NOTE: Make sure the battery Icon at the bottom right of the GDS laptop shows at least 50%; If not, charge the GDS or attach a battery charger.
Turn off all lights (Do not leave the headlight switch in auto mode) and all accessories (including heater/air conditioner/fan, audio, heated seats, rear defroster, etc) to ensure the battery will not be discharged during the update.
Perform the update with the ignition key in the ON position. (Turn ignition key to the ON position or press the Start-Stop button 2 times without depressing the brake pedal).
Do not disconnect any cables connected to the vehicle or the GDS during the update.
Do not start the engine or turn the ignition switch OFF during the update.

SERVICE PROCEDURE

GDS AUTO MODE ECM UPDATE PROCEDURE

From the GDS home page, select ECU Upgrade . If necessary, select the VIN.
Select Engine as the system and then select OK .
Select Auto Mode and then select Next .
From the System tab, select Engine and then select OK . The GDS will read the ROM ID. Confirm the ROM is applicable as shown on Page 1, "ROM ID Information".
Select update event as listed on the GDS Event list of page-1. Select Upgrade .
If the screen indicates "Voltage is OK" (voltage > 12volts), select OK . If not, select CANCEL and charge the vehicle battery by running the engine for 10 minutes.
Updating will occur until 100% is reached on the bar graph. At the prompt, turn OFF ignition 10 seconds then turn ON (pushbutton start pressed 2 times without depressing brake pedal) before going to engine start. Select OK.
The GDS will confirm that ECM reprogramming is successfully finished. Select OK .
If the ECM update was not successful, go to GDS MANUAL MODE ECM UPDATE PROCEDURE .
Check for DTC in all systems and Erase All DTC that stored due to loss of CAN communication during the ECM Update.
Start the engine to confirm proper operation.

GDS MANUAL MODE ECM UPDATE PROCEDURE

NOTE:

GDS Manual Mode la intended for recovery of an ECM Update should it begin but then later fail in process in the Auto Mode.
The ECM connectors must be disconnected for 15 minutes to reset its contents before performing this Manual Mode Update.
Do not force Manual Mode if an error in Auto Mode indicates that the vehicle's current ROM ID did not apply.
It is critical to identify the correct ECM Part Number in the PASSWORD table to prevent the ECM from becoming permanently damaged. It is recommended to remove the ECM and read the part number from the label It it Is not clear which choice to use In the table.

From the GDS home page, select ECU Upgrade . If necessary, select the VIN.
Select Engine as the system and then select OK .
Select Manual Mode and then select Next
From the System tab, select Engine and then select OK .
Select update event as per the GDS Event List of page-1 , then select Upgrade .
Be certain to enter the exact appropriate password from the table on the next page and select OK. See the important NOTE above .
The remaining steps are same as Steps 6-12 of the Auto Procedure.

PASSWORD DESCRIPTION

MENU	PASSWORD
JM 2.0 -IMMO : 39180/39181-23132	3132
JM 2.0 -IMMO : 39180/39181-23133	3133
JM 2.0 -IMMO : 39180/39181-23134	3134

CUSTOMER COMMUNICATION LETTER

SERVICE NOTIFICATION

Dear 2007-2009 Tucson Owner:

Since launching the Tucson in 2005 Hyundai has continued to make refinements in these vehicle that help to ensure your satisfaction. This letter provides you with information about a software update for certain 2007-2009 model year Tucsons.

We recognize that having this service performed will be an inconvenience to you, so we have arranged for you to receive a $25 cash gift card in the mail upon completion of this software update.

NOTE: This is not a credit card it is a gift. Simply dispose of the card after folly using the $25 value.

What should you do?

Please schedule an appointment at your convenience to take your vehicle to your Hyundai dealer. When you make an appointment, please confirm the dealer's schedule to determine how much time will be required to perform the work so you may plan appropriately.
To help facilitate the process, you can schedule an online appointment. Please visit Hyundai.com, click on "Find a Dealer" and input your zip code. When your preferred dealer appears, click on "Schedule Service" under their address.
- If you already have a log-on and password for online scheduling, enter them here, click on "Log In", them click on "Repair". Select "Campaign" and in the "Repair Service " box, enter to code: TUCSON-TF4 and click on "OK". Follow the instructions on the next screens to schedule your appointment.
- If you do not have a log-on and password, complete the information under "New Customer" and click on "Repair". Select "Campaign" and in the "Repair Service" box, enter the code: TUCSON-TF4 and click on "OK". Follow the instructions on the next screens to schedule your appointment.
If your preferred dealer does not have a link to schedule service online, please contact them via phone to schedule an appointment.

What if you have other questions?

If you have any questions related to this service, please contact, the Hyundai Customer Connect Center at 1-800-633-5151 or ConsumerAffairs@hmausa.com.

We thank you for your purchase of your Tueson and hope for your continued satisfaction as a Hyundai owner.

HYUNDAI MOTOR AMERICA

HMA TF4
