Power Tailgate Motor Assembly Replacement

  1. Remove the rear seat assembly. (See REPLACEMENT )
  2. Remove the luggage trim. (See LUGGAGE SIDE TRIM REPLACEMENT )
  3. Disconnect the clip (A), remove the tailgate lifter (B).
    Fig 1: Identifying Tailgate Lifter And Clip
    G05324489Courtesy of HYUNDAI MOTOR CO.
  4. Disconnect the connector.
  5. After loosening the mounting bolts, then remove the tailgate motor assembly (A).
    Fig 2: Tailgate Motor Assembly Mounting Bolts With Torque Specifications
    G05324504Courtesy of HYUNDAI MOTOR CO.
  6. Installation is the reverse of removal.
NOTE:
  • Make sure the connector is plugged in properly.
  • Make sure the tailgate opens properly and locks securely.
