Armrest Replacement

  1. Loosening the armrest mounting screw and nut.
  2. Remove the armrest (A).
    Fig 1: Identifying Armrest
    G04881239Courtesy of HYUNDAI MOTOR CO.
  3. Installation is the reverse of removal.
