Sunroof Assembly Replacement

Remove the follows parts.
- Front and rear door scuff trim (See FRONT DOOR SCUFF TRIM REPLACEMENT and REAR DOOR SCUFF TRIM REPLACEMENT ).
- Front, center and rear pillar trim (See INTERIOR TRIM ).
- Headlining (See ROOF TRIM REPLACEMENT ).
- Sunroof glass (See REPLACEMENT ).
Disconnect the drain tubes (A) and motor connector.
Remove the assist handle bracket (D).
After loosening the mounding bolts and nuts, remove the sunroof assembly (B).
NOTE: Take care not to scratch the interior trims and other Parts.
Installation is the reverse of removal.

Fig 1: Identifying Drain Tubes, Assist Handle Bracket And Sunroof Assembly
Courtesy of HYUNDAI MOTOR CO.
