Trunk Lid Latch Replacement

  1. Loosening the tunk lid latch mounting bolts.
  2. Disconnect the tunk lid latch rod.
  3. Remove the tunk lid latch (A).
    Fig 1: Trunk Lid Latch With Torque Specification
    G04802678Courtesy of HYUNDAI MOTOR CO.
  4. Installation is the reverse of removal.
