Power Window Switch Replacement

  1. Remove the door trim(See REAR DOOR TRIM REPLACEMENT  ).
  2. Remove the power window switch (A).
    Fig 1: Identifying Power Window Switch
    G04802728Courtesy of HYUNDAI MOTOR CO.
  3. Installation is the reverse of removal.
