Power Circuit Inspection

Measure voltage between each terminal (C09) of the sensor harness connector and chassis ground.

Specification:

VOLTAGE SPECIFICATIONS CHART

TERMINAL (C151)	1	2	3	4	5	6	7	8	9	10
SPECIFICSTION	0V	0V	0V	0V	0V	0V	0V	0V	0V	0V

Fig 1: Measuring Voltage Between Terminal (C09) Of Sensor Harness Connector And Chassis Ground

Courtesy of HYUNDAI MOTOR CO.

Is voltage within specifications?
Yes:
- Go to "SIGNAL CIRCUIT INSPECTION " procedure.
No:
- Check for Short in harness. Repair as necessary and Go to "VERIFICATION OF VEHICLE REPAIR " procedure.
