Cruise Control Unit And Cable: Notes

Loosen the locknuts (A) and disconnect the actuator cable (B) from the throttle linkage (C).

Fig 1: Loosening Locknuts And Disconnecting Actuator Cable From Throttle Linkage
Courtesy of HYUNDAI MOTOR CO.
Disconnect the cruise control unit connector (D).
Loosen the three mounting bolts (E), and remove the cruise control unit with the bracket (F).

Fig 2: Loosening Three Mounting Bolts And Removing Cruise Control Unit With Bracket
Courtesy of HYUNDAI MOTOR CO.
Loosen the locknuts (A) and disconnect the actuator cable (B) from the cruise control unit.

Fig 3: Loosening Locknuts And Disconnecting Actuator Cable From Cruise Control Unit
Courtesy of HYUNDAI MOTOR CO.
Installation is the reverse of removal.
