Inspection Procedure 2

INSPECTION PROCEDURE 2 - TROUBLESHOOTING SYMPTOM

Starting impossible Probable cause
Starting is not possible when the selector lever is in P or N range. In such cases, the cause is possibly a defective engine system, torque converter or oil pump.
  • Malfunction of the engine system
  • Malfunction of the torque converter
  • Malfunction of the oil pump
Fig 1: Starting Impossible - Troubleshooting Flow Chart
G03858296Courtesy of HYUNDAI MOTOR CO.
