Trunk Lid Latch Replacement

  1. Disconnect the key cylinder connecting rod (A).
  2. Loosen the latch mounting bolts (B) and disconnect the inside handle cable (C).
    Fig 1: Disconnecting Inside Handle Cable & Torque Specifications
    G03843829Courtesy of HYUNDAI MOTOR CO.
  3. Installation is the reverse of removal.
    NOTE:
    • Make sure the connector is connected properly and the key cylinder rod is connected properly.
    • Make sure the trunk lid opens properly and locks securely.
