Inspection Procedure 6

WARNING: This page is about a different variant/trim than selected.
Fig 1: Engine Stalling During Shifting Probable Cause Table
G00963496Courtesy of HYUNDAI MOTOR CO.
Fig 2: Engine Stalling During Shifting Flow Chart
G00963497Courtesy of HYUNDAI MOTOR CO.
