Inspection Procedure 2

WARNING: This page is about a different variant/trim than selected.
Fig 1: Starting Impossible (Won't Crank) Probable Cause Table
G00963488Courtesy of HYUNDAI MOTOR CO.
Fig 2: Starting Impossible (Won't Crank) Flow Chart
G00963489Courtesy of HYUNDAI MOTOR CO.
