Installation Procedure

WARNING: This page is about a different car, the 2004 Hummer H2. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: A/C Compressor Relay & Convenience Center
    GM828240Courtesy of GENERAL MOTORS CORP.
  1. Install the A/C compressor relay (1) to the convenience center (2).
  2. Install the cover to the underhood convenience center (1).
