DTC C0020-12: Inspection
PGND Open Wire Inspection
Test Procedure
- Preparation
- VSA modulator-control unit connector (46P): disconnected
- Procedure
- Perform the inspection according to the following chart.
| (Disconnected) VSA modulator-control unit connector (46P) female terminals | ||||
| IG Mode |
|
Normal Conditions | ||
| PGND open wire inspection | OFF | There is less than 1 Ω |
Results
- If normal, there is a problem with the VSA modulator-control unit.
- If abnormal, there is a problem in the circuit.
