BSI Radar Unit Aiming Inspection: Notes

Special Tools Required

Image	Description/Tool Number
Courtesy of HONDA, U.S.A., INC.	Rim Frame Extension 07AAK-TM0A100
Courtesy of HONDA, U.S.A., INC.	Stand 07AAJ-TK8A100*
Courtesy of HONDA, U.S.A., INC.	Rim Frame 07AAJ-TK8A150
Courtesy of HONDA, U.S.A., INC.	Target Set 07AAJ-STKA160
Courtesy of HONDA, U.S.A., INC.	Angle Gauge 07AAJ-STKA170
Courtesy of HONDA, U.S.A., INC.	Stand Set 07AAJ-STKA220*

*: Use Stand 07AAJ-TK8A100 or Stand Set 07AAJ-STKA220 for aiming.
