Washer Reservoir Replacement

WARNING: This page is about a different car, the 2011 Honda Pilot, 2010 Honda Pilot, and 2009 Honda Pilot. However, it is still accessible from the selected car via links, so may be relevant.

Open the hood, and remove the front bumper (see FRONT BUMPER REMOVAL/INSTALLATION ).
Disconnect the 2P connectors (A) from the washer motors (B) and the washer fluid level switch.

Fig 1: Identifying 2P Connectors
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Disconnect the washer tubes.
Remove the two bolts and clip (A), then remove the washer reservoir.

Fig 2: Washer Reservoir Bolts & Clip With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install in the reverse order of removal. Check the washer motor operation.
