Tailgate Trim Panel Removal/Installation

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2014 Honda Ridgeline, 2013 Honda Ridgeline, 2012 Honda Ridgeline, 2011 Honda Ridgeline, and 2010 Honda Ridgeline. However, it is still accessible from the selected car via links, so may be relevant.

Open the tailgate.
NOTE:
- The tailgate trim panel can be removed with the tailgate open in either the drop-down mode or swing mode.
- The drop-down mode is shown; the swing mode is similar.
Remove the tailgate top trim (A).
1. -1 Remove the screws.
2. -2 Using a rubber mallet, slide the top trim to the right, and remove it. The upper clips will stay in the tailgate.
3. -3 Remove the upper clips from the tailgate.
Fig 1: Identifying Tailgate Top Trim
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Remove the bolts using a TORX T40 bit, and then remove the tailgate trim panel (A).

Fig 2: Tailgate Trim Panel And Bolts With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install the trim panel in the reverse order of removal, and note these items:
- If the clips are damaged or stress-whitened, replace them with new ones.
- Before reinstalling the top trim, install the upper clips on the trim. Hold the trim up, and fit all the upper clips into the holes in the tailgate, then push on the trim until the clips snap into place.
