Backlash Inspection

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2014 Honda Ridgeline, 2013 Honda Ridgeline, 2012 Honda Ridgeline, 2011 Honda Ridgeline, and 2010 Honda Ridgeline. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Connecting battery voltage to either the right or left clutch electromagnetic coils for more than 3 minutes will damage the rear differential.

Install the left rear driveshaft.
At the left clutch electromagnetic coil side, connect the left clutch electromagnetic coil 2P connector (A) terminal No. 1 to the battery positive terminal, and connect the terminal No. 2 to the battery negative terminal.

Fig 1: Identifying Backlash Of Companion Flange With Dial Indicator
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Check the backlash of the companion flange (B) with a dial indicator (C).
Standard: 1.23-2.38 mm (0.048-0.094 in.)
If the backlash is out of standard, replace the rear differential.
