Gray Tone

WARNING: This page is about a different variant/trim than selected.

This screen diagnoses problems with contrast. You should be able to see the changes from bar to bar across the scale. It is normal for the two bars on either side to appear the same. If you can't see changes from bar to bar, replace the navigation unit.

Fig 1: Display - Gray Tone
G06229756Courtesy of AMERICAN HONDA MOTOR CO., INC.
