GPS Initialization

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2017 Honda Odyssey, 2016 Honda Odyssey, 2015 Honda Odyssey, 2014 Honda Odyssey, and 2013 Honda Odyssey. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: You must park the vehicle outside with a clear view of the sky.

Depending on the length of time the battery was disconnected, your system may require GPS initialization. If it does, the following screen appears:

Fig 1: GPS Initialization Screen Display

Courtesy of AMERICAN HONDA MOTOR CO., INC.

If this procedure is not necessary, the system proceeds directly to the Disclaimer screen. During initialization, the system searches for all available GPS satellites, and obtains their orbital information. During this procedure the vehicle should be out in the open with a clear view of the sky.

If the navigation system finds the satellites properly, this box clears, and changes to the Disclaimer screen. If within 10 minutes the system fails to locate a sufficient number of satellites to locate your position, the following screen appears.

Fig 2: GPS Initialization Disclaimer Screen Display

Courtesy of AMERICAN HONDA MOTOR CO., INC.

If this screen appears, turn off the engine, then restart the vehicle and move it to a different outdoor location. If the Disclaimer screen appears, the GPS initialization is complete.

NOTE:

The average acquiring time is less than 10 minutes, but it can take as long as 45 minutes.
If the system is still unable to acquire a signal, follow the instructions on the screen. If this screen appears again, go to GPS ICON IS WHITE OR NOT SHOWN TROUBLESHOOTING .
Skip to a CSF screen by pushing the DEST/ROUTE and INFO buttons at the same time and can move to a System Links screen.
