Crankshaft Position (CKP) Sensor

The CKP sensor detects crankshaft speed and is used by the ECM/PCM to determine ignition timing and timing for fuel injection of each cylinder as well as detecting engine misfire.

Fig 1: Identifying Crankshaft Position (CKP) Sensor
G05448872Courtesy of AMERICAN HONDA MOTOR CO., INC.
