Installation ('09-11 Models)

  1. Set the accelerator pedal pad (A) to the pedal stop (B).
    Fig 1: Disconnecting Accelerator Pedal Module Connector
    G00485214Courtesy of TOYOTA
  2. Install the accelerator pedal module (C) with a new clip (D).
  3. Reconnect the APP sensor 6P connector (E).
