Throttle Position (TP) Sensor

The TP sensor is a potentiometer connected to the throttle valve shaft. As the throttle position changes, the sensor varies the signal voltage to the ECM/PCM. The TP sensor is not available separately from the throttle body.

Fig 1: Identifying Throttle Position Sensor Terminal

Courtesy of AMERICAN HONDA MOTOR CO., INC.
