Home >> Honda >> 2003 >> Civic Si >> Repair and Diagnosis >> External Pages >> Different car >> Section 62 (Interior Lights) >> Courtesy Light Replacement

Courtesy Light Replacement

WARNING: This page is about a different car, the 2006 Acura MDX, 2005 Acura MDX, 2004 Acura MDX, and 2003 Acura MDX. However, it is still accessible from the selected car via links, so may be relevant.
  1. Carefully pry off the lens (A) with a small screwdriver.

    COURTESY LIGHT: 3.8 W

    Fig 1: Prying Off Lens With Screwdriver
    G03642175Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Remove the bulb (B) from the socket.
  3. Install in the reverse order of removal.
