Tailgate Weatherstrip Replacement

WARNING: This page is about a different car, the 2006 Acura MDX, 2005 Acura MDX, 2004 Acura MDX, and 2003 Acura MDX. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the tailgate weatherstrip (A) by pulling out on it.
    Fig 1: Removing Tailgate Weatherstrip
    G03641763Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Locate the painted alignment mark (B) on the tailgate weatherstrip. Align the painted mark with the alignment tab in the center of the tailgate opening, and install the tailgate weatherstrip all the way around in the direction shown. Make sure there are no wrinkles in the weatherstrip.
  3. Check for water leaks.
