Front Door Weatherstrip Replacement

NOTE:
  • Take care not to scratch the door.
  • Use a clip remover to remove the clips.
  1. At the front pillar, remove the door checker mounting bolt (A).
    Fig 1: Removing Door Checker Mounting Bolt
    G01473982Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Detach the clips (B, C), then remove the door weatherstrip (D).
  3. Install the weatherstrip in the reverse order of removal, and note these items:
    • Replace any damaged clips.
    • Make sure the weatherstrip is installed in the holder (E) securely.
    • Apply liquid thread lock to the door checker mounting bolt before installation.
    • Check for water leaks (see step  7 on ).
    • Test-drive and check for wind noise.
