Front Door Weatherstrip Replacement

WARNING: This page is about a different car, the 2006 Honda Odyssey and 2005 Honda Odyssey. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
  • Take care not to scratch the door.
  • Use a clip remover to remove the clips.
  1. Remove the power mirror (see POWER MIRROR REPLACEMENT ).
  2. Remove the door checker mounting bolt (A).
    Fig 1: Removing Door Checker Mounting Bolt
    G03705707Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Detach the clips (B, C), then remove the door weatherstrip (D).
  4. Install the weatherstrip in the reverse order of removal, and note these items:
    • Check the clips for damage or stress-whitening, and replace them with new one.
    • Make sure the weatherstrip is installed in the holder (E) securely.
    • Apply liquid thread lock to the door checker mounting bolt before installation.
    • Check for water leaks (see step 7 in FRONT DOOR GLASS ADJUSTMENT  ).
