Fuel Metering Lean Faulty Inspection Procedure

NOTE: See appropriate WIRING DIAGRAM in WIRING DIAGRAMS  section for terminal and connector identification.

Fig 1: Fuel Metering Lean - Diagnostic Flowchart (2.6L Passport)

Courtesy of ISUZU MOTOR CO.
