System Tests

For testing procedure, refer to flowchart. See Fig 1, Fig 2 and Fig 3 .

Fig 1: System Test Diagnostic Flowchart (1 Of 3)

Courtesy of GENERAL MOTORS CORP.

Fig 2: System Test Diagnostic Flowchart (2 Of 3)

Courtesy of GENERAL MOTORS CORP.

Fig 3: System Test Diagnostic Flowchart (3 Of 3)

Courtesy of GENERAL MOTORS CORP.
