Home >> Genesis >> 2021 >> GV80 3.5T Advanced >> Repair and Diagnosis >> Body & Frame >> Door Locks >> Smart Key System >> Smart Key Antenna >> Repair Procedures >> Removal >> Tailgate open

Tailgate open

  1. Disconnect the negative (-) battery terminal.
  2. Remove the rear wiper motor.

    (Refer to Rear Wiper/washer - "REAR WIPER MOTOR ")

  3. Remove the tailgate open switch (A).
    G14723832Courtesy of HYUNDAI MOTOR AMERICA
