Repair Procedures: Removal

  1. Disconnect the negative (-) battery terminal.
  2. Remove the mirror wiring cover (A) and rain sensor cover (B).
  3. Remove the front view camera connector (A).
  4. Remove the front view camera (B) after disengaging the mounting bracket.
    G14178257Courtesy of HYUNDAI MOTOR AMERICA
