| 1 |
IGN |
1 |
Retractor pretensioner-Front, Driver-High (+) |
| 2 |
- |
2 |
Retractor pretensioner-Front, Driver-Low (-) |
| 3 |
Driver airbag 1st stage-High (+) |
3 |
Retractor pretensioner-Front, Passenger-Low (-) |
| 4 |
Driver airbag 1st stage-Low (-) |
4 |
Retractor pretensioner-Front, Passenger-High (-) |
| 5 |
Passenger airbag (1st stage - Low) |
5 |
- |
| 6 |
Passenger airbag (1st stage - High) |
6 |
- |
| 7 |
Driver airbag 2nd stage-High (+) |
7 |
- |
| 8 |
Driver airbag 2nd stage-Low (-) |
8 |
- |
| 9 |
Passenger airbag 2nd stage - Low (-) |
9 |
Side airbag-Front, Driver-High (+) |
| 10 |
Passenger airbag 2nd stage - High (+) |
10 |
Side airbag-Front, Driver-Low (+) |
| 11 |
C-CAN-LOW (-) |
11 |
GND |
| 12 |
- |
12 |
Side airbag-Front, Driver-Passenger-High (+) |
| 13 |
- |
13 |
Side airbag-Front, Driver-Passenger-Low (-) (+) |
| 14 |
- |
14 |
Side airbag-Rear, Driver-Low |
| 15 |
- |
15 |
Side airbag-Rear, Driver-High |
| 16 |
- |
16 |
Side airbag-Rear, Passenger-High (+) |
| 17 |
- |
17 |
Side airbag-Rear, Passenger-Low (-) |
| 18 |
Passenger airbag active vent-High (+) |
18 |
- |
| 19 |
Passenger airbag active vent-Low (-) |
19 |
- |
| 20 |
Knee airbag-Driver-Low (-) |
20 |
- |
| 21 |
Knee airbag-Driver-High (+) |
21 |
- |
| 22 |
C-CAN-High (+) |
22 |
P-CAN-LOW (-) |
| 23 |
- |
23 |
Curtain airbag-Driver-High |
| 24 |
- |
24 |
Curtain airbag-Driver-Low |
| 25 |
- |
25 |
Curtain airbag-Passenger-Low (-) |
| 26 |
- |
26 |
Curtain airbag-Passenger-High (+) |
| 27 |
- |
27 |
- |
| 28 |
- |
28 |
Side Impact sensor-Rear, Driver-High (+) |
| 29 |
- |
29 |
Side Impact sensor-Rear, Driver-Low (-) |
| 30 |
- |
30 |
- |
| 31 |
- |
31 |
- |
| 32 |
Anchor pretensioner-Driver-High (+) |
32 |
Seat belt buckle sensor-Front, Driver |
| 33 |
Anchor pretensioner-Driver-Low (-) |
33 |
P-CAN-HIGH (+) |
| 34 |
- |
34 |
Side impact sensor-Front, Driver-High (+) |
| 35 |
Telltale lamp |
35 |
Side impact sensor-Front, Driver-Low (-) |
| 36 |
- |
36 |
Side impact sensor-Front, Passenger-High (+) |
| 37 |
Crash output |
37 |
Side impact sensor-Front, Passenger-Low (-) |
| 38 |
Passenger SBR |
38 |
Pressure side impact sensor-Driver-High (+) |
| 39 |
Front impact sensor-Driver-High (+) |
39 |
Pressure side impact sensor-Driver-Low (-) |
| 40 |
Front impact sensor-Driver-Low (-) |
40 |
Pressure side impact sensor-Passenger-High (+) |
| 41 |
Front impact sensor-Passenger-High (+) |
41 |
Pressure side impact sensor-Passenger-Low (-) |
| 42 |
Front impact sensor-Passenger-Low (-) |
42 |
Side impact sensor-Rear, Passenger-High (+) |
| 43 |
Anchor pretensioner-Passenger-High (+) |
43 |
Side impact sensor-Rear, Passenger-Low (-) |
| 44 |
Anchor pretensioner-Passenger-Low (-) |
44 |
Seat belt buckle sensor-Front, Passenger |
