Repair Procedures: Specification
WARNING: This page is about a different car, the 2017 Genesis G80. However, it is still accessible from the selected car via links, so may be relevant.
| Evaporator core temperature [°C(°F)] |
Resistance[KΩ] |
Voltage[V] |
| -10 (14) |
43.35 |
2.96 |
| 0 (32) |
27.62 |
2.4 |
| 10 (50) |
18.07 |
1.88 |
| 20 (68) |
12.11 |
1.44 |
| 30 (86) |
8.3 |
1.08 |
| 40 (104) |
5.81 |
0.81 |
