[Tau Engine]

WARNING: This page is about a different car, the 2017 Genesis G80. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Heater And A/C Controller Unit (Tau Engine) With Torque Specifications

Courtesy of HYUNDAI MOTOR AMERICA
