Repair Procedures: Replacement

WARNING: This page is about a different car, the 2017 Genesis G90. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim.

    (Refer to Front Door - "FRONT DOOR TRIM ")

  2. After loosening the mounting screws, remove the front door inside handle (A).
    Fig 1: Removing Front Door Inside Handle With Mounting Screws
    G11405486Courtesy of HYUNDAI MOTOR AMERICA
  3. To install, reverse the removal procedure.

    Information

    • Make sure the connector is connected properly.
    • Make sure the door locks/unlocks and opens/closes properly.
    • Replace any damaged clips.
