Repair Procedures: Removal

WARNING: This page is about a different car, the 2017 Genesis G80. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the negative (-) battery terminal.
Remove the steering column upper shrouds (A).
(Refer to STEERING COLUMN SHROUD LOWER PANEL )

Courtesy of
Disconnect the multifunction switch connector (A).

Courtesy of
Remove the wiper switch (A) by pushing the lock pin (B).
NOTE: When removing the wiper & washer switch only, release the lock of wiper switch without removing the steering wheel.

Courtesy of
If it is necessary to remove multifunction switch assembly, remove the steering wheel.
(Refer to STEERING WHEEL )
Remove the clock spring.
(Refer to Restraint - "DRIVER AIRBAG (DAB) MODULE AND CHECK SPRING )

Courtesy of
Loosening the screws (2EA) from the multifunction switch assembly (A).

Courtesy of
