Repair Procedures: Disassembly

  1. Remove the engine room under cover.

    (For 2.0L, refer to - "ENGINE ROOM UNDER COVER ". For 3.3L, refer to - "ENGINE ROOM UNDER COVER ".)

  2. Remove the front wheel guard.

    (Refer to Body - "FRONT WHEEL GUARD ")

  3. Loosen the drive belt.

    (For 2.0L, refer to - "DRIVE BELT ". For 3.3L, refer to - "DRIVE BELT ".)

  4. Remove the clutch bolt while holding the pulley with a clutch bolt remover (09977-3R000).

    Tightening torque:

    9.8 - 14.7 N.m (1.0 - 1.5 kgf.m, 7.2 - 10.8 lb-ft)

    G13542368Courtesy of HYUNDAI MOTOR AMERICA
  5. Loosen the limiter bolts and then remove the limiter & hub assembly.
    G13542369Courtesy of HYUNDAI MOTOR AMERICA
  6. Remove the pulley (B) after removing the snap ring (A) with a snap ring plier.
    G13542370Courtesy of HYUNDAI MOTOR AMERICA
    G13542371Courtesy of HYUNDAI MOTOR AMERICA
    NOTE:
    • Be careful not to damage the pulley and compressor during disassembly/reassembly.
    • Once the snap ring is removed, replace it with a new one.
  7. Reassemble in the reverse order of disassembly.
    • Clean the pulley and compressor sliding surfaces with non-petroleum solvent.
    • Install a new snap ring, and make sure they are fully seated in the groove.
    • Make sure that the pulley turns smoothly after reassembly.
