Exhaust System Alignment (L5P)

  1. GM4571357

    Front Wheelhouse Liner-Right (2) - Remove - Front Wheelhouse Liner Replacement - Right Side

  2. GM4573771

    Exhaust Pipe Heat Shield (2) - Remove - Exhaust Pipe Heat Shield Replacement - Right Side (L5P)

  3. GM4584578

    Exhaust Front Bracket Nut (1) - [2x] Remove - Exhaust Front Bracket Replacement - Lower (L5P)

  4. GM4584603

    Loosen the lower exhaust front bracket to flywheel housing bolts (1) 1/4 turn each [2x].

  5. GM4584461
    NOTE:

    If the stud plate assembly cannot be removed, further loosen the lower exhaust front bracket to flywheel housing bolts, remove the stud plate assembly, then hand tighten the bolts and reverse 1/4 turn.

    Exhaust Front Pipe Stud Plate Assembly (1) - Remove

  6. GM4584714

    Exhaust Front Bracket Bolt - Upper (1) - Loosen [4x] - Exhaust Front Bracket Replacement - Upper (L5P)

  7. GM4577117

    Loosen the catalytic converter clamp (1) approximately 3.5 turns or just enough to allow the exhaust front pipe flange to rotate.

  8. GM4584325

    Loosen the turbocharger to catalytic converter band clamp (1) approximately 3.5 turns or just enough to allow the converter flange to rotate.

  9. GM4584485

    Adjust the alignment of the exhaust front pipe (1) to catalytic converter by rotating, raising or lowering the pipe until the holes of the lower flange align with the lower exhaust front bracket (2).

  10. Use vise grips to clamp the lower exhaust front bracket to the exhaust front pipe flange.
  11. GM4577117

    Catalytic Converter Clamp (1) - Tighten - Exhaust Front Pipe Replacement (L5P)

  12. GM4584325

    Catalytic Converter Clamp (1) - Tighten - Oxidation Catalytic Converter Replacement (L5P)

  13. GM4584603

    Exhaust Front Bracket Bolt - Lower (1) - Tighten [2x] - Exhaust Front Bracket Replacement - Lower (L5P)

  14. Remove the vise grips.
  15. GM4584461

    Install the stud plate assembly (1) through the exhaust front bracket and exhaust front pipe flange holes.

  16. GM4584714

    Exhaust Front Bracket Bolt - Upper (1) - Tighten [4x] - Exhaust Front Bracket Replacement - Upper (L5P)

  17. GM4584578

    Exhaust Front Bracket Nut (1) - Tighten [2x] - Exhaust Front Bracket Replacement - Lower (L5P)

  18. GM4573771

    Exhaust Pipe Heat Shield (2) - Install - Exhaust Pipe Heat Shield Replacement - Right Side (L5P)

  19. GM4571357

    Front Wheelhouse Liner-Right (2) - Install - Front Wheelhouse Liner Replacement - Right Side
