Lighting Systems Schematic Icons

WARNING: This page is about a different car, the 2007 Cadillac XLR. However, it is still accessible from the selected car via links, so may be relevant.
Lighting Systems Schematic Icons

Icon Icon Definition
GM296943Courtesy of GENERAL MOTORS CORP.
CAUTION: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns:
  • Never open the high intensity discharge system ballast or the arc tube assembly starter.
  • Never probe between the high intensity discharge system ballast output connector and the arc tube assembly.
