Installation Procedure

    Fig 1: View Of Transfer Case Adapter, Bolts & Seal
    GM652614Courtesy of GENERAL MOTORS CORP.
    IMPORTANT: Do not reuse the old gasket if it is damaged, replaced it. Do not use any type of sealer in place of the gasket.
  1. Install the new transfer case adapter seal.
  2. Install the transfer adapter to the transmission.
    3. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the transfer case adapter mounting bolts to the transmission.

    Tighten:  Tighten the transfer case adapter mounting bolts to 55 N.m (40 lb ft).

    4. Fig 2: View Of Transfer Case Gasket
    GM654219Courtesy of GENERAL MOTORS CORP.
  4. Install the new transfer case gasket.
    5. Fig 3: Supporting Transfer Case With Transmission Jack
    GM648037Courtesy of GENERAL MOTORS CORP.
  5. Install the transfer case assembly. Refer to Transfer Case Assembly Replacement .
