Special Tools

Fig 1: Snap Ring Pliers (J-8059)
G00330033Courtesy of GENERAL MOTORS CORP.
Fig 2: Axle Seal Clamp Pliers (J-35910)
G00330027Courtesy of GENERAL MOTORS CORP.
Fig 3: Seal Clamp Pliers (J-35566)
G00330032Courtesy of GENERAL MOTORS CORP.
Fig 4: Axle Seal Clamp Pliers (J-35910)
G00330027Courtesy of GENERAL MOTORS CORP.
Fig 5: Drive Axle Swage Ring Clamp (J-41048)
G00330045Courtesy of GENERAL MOTORS CORP.
