Removal Procedure

  1. Raise the vehicle.
  2. Remove the wiring harness connector from the KS (2).
  3. Remove the KS (2) from the engine block (1).
    Fig 1: Knock Sensor & Harness Connector (2)
    G01599016Courtesy of GENERAL MOTORS CORP.
