Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the left side of the instrument panel (I/P) insulator.
  2. Disconnect the electrical connector from the stop lamp switch.
  3. Remove the stop lamp switch (2) from the brake pedal bracket.
    Fig 1: Removing Stop Lamp Switch From Brake Pedal Bracket
    G01503202Courtesy of GENERAL MOTORS CORP.
